AON6946
lmages are for reference only.AON6946
MOSFET 2N-CH 30V 14A/18A 8DFN
Datasheet8-PowerVDFN
47,656 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Mosfet Array 30V 14A, 18A 3.5W, 3.9W Surface Mount 8-DFN (5x6)
AON6946
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Alpha & Omega Semiconductor Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Technology | MOSFET (Metal Oxide) |
| Configuration | 2 N-Channel (Dual) Asymmetrical |
| FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 14A, 18A |
| Rds On (Max) @ Id, Vgs | 11.6mOhm @ 13A, 10V |
| Vgs(th) (Max) @ Id | 2.2V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 15nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 485pF @ 15V |
| Power - Max | 3.5W, 3.9W |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerVDFN |
| Supplier Device Package | 8-DFN (5x6) |
| Base Product Number | AON694 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | AON6810 | AON6812 | AON6816 | AON6850 |
| Manufacturer | Alpha & Omega Semiconductor Inc. | Alpha & Omega Semiconductor Inc. | Alpha & Omega Semiconductor Inc. | Alpha & Omega Semiconductor Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET 2N-CH 30V 25A 8DFN | MOSFET 2N-CH 30V 27A 8DFN | MOSFET 2N-CH 30V 17A 8DFN | MOSFET 2N-CH 100V 5A 8DFN |
| Series | - | - | - | SDMOS™ |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
