Product CatalogPart Number
AOTF15B65M1
Manufacturer
Alpha & Omega Semiconductor Inc.Description
IGBT 650V 15A TO220
Datasheet
DatasheetPackage
TO-220-3
In Stock
22,482 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
AOTF15B65M1
AOTF15B65M1
lmages are for reference only.Payment Methods
Delivery Services
IGBT 650 V 30 A 36 W Through Hole TO-220
Quick Inquiry
AOTF15B65M1
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Alpha & Omega Semiconductor Inc. |
| Series | Alpha IGBT™ |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | - |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
| Current - Collector (Ic) (Max) | 30 A |
| Current - Collector Pulsed (Icm) | 45 A |
| Vce(on) (Max) @ Vge, Ic | 2.15V @ 15V, 15A |
| Power - Max | 36 W |
| Switching Energy | 290µJ (on), 200µJ (off) |
| Input Type | Standard |
| Gate Charge | 32 nC |
| Td (on/off) @ 25°C | 15ns/94ns |
| Test Condition | 400V, 15A, 20Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 |
| Supplier Device Package | TO-220 |
| Reverse Recovery Time (trr) | 317 ns |
| Base Product Number | AOTF15 |
