AOTF15B65M3
lmages are for reference only.AOTF15B65M3
IGBT 650V 15A TO-220F
DatasheetTO-220-3 Full Pack
51,089 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT 650 V 30 A 30 W Through Hole TO-220F
AOTF15B65M3
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Alpha & Omega Semiconductor Inc. |
| Series | Alpha IGBT™ |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | - |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
| Current - Collector (Ic) (Max) | 30 A |
| Current - Collector Pulsed (Icm) | 45 A |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 15A |
| Power - Max | 30 W |
| Switching Energy | 280µJ (on), 190µJ (off) |
| Input Type | Standard |
| Gate Charge | 25.4 nC |
| Td (on/off) @ 25°C | 10ns/68ns |
| Test Condition | 400V, 15A, 20Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 Full Pack |
| Supplier Device Package | TO-220F |
| Reverse Recovery Time (trr) | 263 ns |
| Base Product Number | AOTF15 |
| Product Attribute |  |
 |
 |
 |
| Part Number | AOTF15B65M1 | AOTF15B65M2 | AOTF15B65MQ1 | AOTF15B60D |
| Manufacturer | Alpha & Omega Semiconductor Inc. | Alpha & Omega Semiconductor Inc. | Alpha & Omega Semiconductor Inc. | Alpha & Omega Semiconductor Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IGBT 650V 15A TO220 | IGBT 650V 15A TO220 | IGBT 15A | IGBT 600V 30A 50W TO220F |
| Series | Alpha IGBT™ | Alpha IGBT™ | AlphaIGBT™ | Alpha IGBT™ |
| Packaging | Tube | Tube | Tape & Reel (TR) | Tube |
