APT75GN60BDQ2G
Manufacturer
Microchip TechnologyDescription
IGBT TRENCH FS 600V 155A TO247-3
Datasheet
DatasheetPackage
TO-247-3
In Stock
38,606 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
APT75GN60BDQ2G
APT75GN60BDQ2G
lmages are for reference only.Payment Methods
Delivery Services
IGBT Trench Field Stop 600 V 155 A 536 W Through Hole TO-247-3
Quick Inquiry
APT75GN60BDQ2G
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | Trench Field Stop |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 155 A |
| Current - Collector Pulsed (Icm) | 225 A |
| Vce(on) (Max) @ Vge, Ic | 1.85V @ 15V, 75A |
| Power - Max | 536 W |
| Switching Energy | 2.5mJ (on), 2.14mJ (off) |
| Input Type | Standard |
| Gate Charge | 485 nC |
| Td (on/off) @ 25°C | 47ns/385ns |
| Test Condition | 400V, 75A, 1Ohm, 15V |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-247-3 |
| Supplier Device Package | TO-247-3 |
| Reverse Recovery Time (trr) | 25 ns |
| Base Product Number | APT75GN60 |
