APT80SM120S
lmages are for reference only.APT80SM120S
SICFET N-CH 1200V 80A D3PAK
DatasheetTO-268-3, D3PAK (2 Leads + Tab), TO-268AA
79,005 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 1200 V 80A (Tc) 625W (Tc) Surface Mount D3PAK
APT80SM120S
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Microsemi Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| FET Type | N-Channel |
| Technology | SiCFET (Silicon Carbide) |
| Drain to Source Voltage (Vdss) | 1200 V |
| Current - Continuous Drain (Id) @ 25°C | 80A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 20V |
| Rds On (Max) @ Id, Vgs | 55mOhm @ 40A, 20V |
| Vgs(th) (Max) @ Id | 2.5V @ 1mA |
| Vgs (Max) | +25V, -10V |
| Input Capacitance (Ciss) (Max) @ Vds | - |
| FET Feature | - |
| Power Dissipation (Max) | 625W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | D3PAK |
| Package / Case | TO-268-3, D3PAK (2 Leads + Tab), TO-268AA |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 235 nC @ 20 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | APT80SM120B | APT80SM120J | APT8011JFLL | APT8011JLL |
| Manufacturer | Microsemi Corporation | Microsemi Corporation | Microchip Technology | Microchip Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ||
| Description | SICFET N-CH 1200V 80A TO247 | SICFET N-CH 1200V 51A SOT227 | MOSFET N-CH 800V 51A ISOTOP | MOSFET N-CH 800V 51A ISOTOP |
| Series | - | - | POWER MOS 7® | POWER MOS 7® |
| Packaging | Bulk | Bulk | Tube | Tube |
