APTGF50DA120TG
Manufacturer
Microsemi CorporationDescription
IGBT MODULE 1200V 75A 312W SP4
Datasheet
DatasheetPackage
SP4
In Stock
68,155 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
APTGF50DA120TG
APTGF50DA120TG
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module NPT Single 1200 V 75 A 312 W Chassis Mount SP4
Quick Inquiry
APTGF50DA120TG
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Microsemi Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| IGBT Type | NPT |
| Configuration | Single |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 75 A |
| Power - Max | 312 W |
| Vce(on) (Max) @ Vge, Ic | 3.7V @ 15V, 50A |
| Current - Collector Cutoff (Max) | 250 µA |
| Input Capacitance (Cies) @ Vce | 3.45 nF @ 25 V |
| Input | Standard |
| NTC Thermistor | Yes |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | SP4 |
| Supplier Device Package | SP4 |
| Base Product Number | - |
