Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-CDIP (0.300", 7.62mm)
CD54HC273F
| Category | Integrated Circuits (ICs) - Logic - Flip Flops |
| Manufacturer | Texas Instruments |
| Series | 54HC |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Function | Master Reset |
| Type | D-Type |
| Output Type | Non-Inverted |
| Number of Elements | 1 |
| Number of Bits per Element | 8 |
| Clock Frequency | 60 MHz |
| Max Propagation Delay @ V, Max CL | 26ns @ 6V, 50pF |
| Trigger Type | Positive Edge |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Voltage - Supply | 2V ~ 6V |
| Current - Quiescent (Iq) | 8 µA |
| Input Capacitance | 10 pF |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Through Hole |
| Supplier Device Package | 20-CDIP |
| Package / Case | 20-CDIP (0.300", 7.62mm) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
|
| Part Number | CD54HC273F3A | CD54AC109F3A | CD54AC112F3A | CD54AC112F3A |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | HIGH SPEED CMOS LOGIC OCTAL D-TY | DUAL POSITIVE-EDGE TRIGGERED J-K | CD54AC112 DUAL NEGATIVE EDGE TRI | DUAL NEGATIVE EDGE TRIGGERED J-K |
| Series | 54HC | 54AC | * | 54AC |
| Packaging | Tube | Tube | Bulk | Tube |
