CM20TF-12H
Manufacturer
Powerex Inc.Description
IGBT MODULE 600V 20A 125W
Datasheet
DatasheetPackage
Module
In Stock
35,762 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
CM20TF-12H
CM20TF-12H
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module Three Phase Inverter 600 V 20 A 125 W Chassis Mount Module
Quick Inquiry
CM20TF-12H
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Powerex Inc. |
| Series | IGBTMOD™ |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| IGBT Type | - |
| Configuration | Three Phase Inverter |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 20 A |
| Power - Max | 125 W |
| Vce(on) (Max) @ Vge, Ic | 2.8V @ 15V, 20A |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 2 nF @ 10 V |
| Input | Standard |
| NTC Thermistor | No |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Supplier Device Package | Module |
| Base Product Number | - |
