CMF23V-273141-B
Manufacturer
Triad MagneticsDescription
CMC 27MH 1.4A 2LN TH
Datasheet
DatasheetPackage
Vertical, 4 PC Pin
In Stock
57,358 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
CMF23V-273141-B
CMF23V-273141-B
lmages are for reference only.Payment Methods
Delivery Services
27 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 1.4A DCR 484mOhm
Quick Inquiry
CMF23V-273141-B
Specifications
| Category | Filters - Common Mode Chokes - |
| Manufacturer | Triad Magnetics |
| Series | CMF |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 27 mH @ 10 kHz |
| Current Rating (Max) | 1.4A |
| DC Resistance (DCR) (Max) | 484mOhm |
| Voltage Rating - DC | - |
| Voltage Rating - AC | 300V |
| Operating Temperature | -40°C ~ 105°C |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 1.142" L x 0.591" W (29.00mm x 15.00mm) |
| Height (Max) | 1.063" (27.00mm) |
| Package / Case | Vertical, 4 PC Pin |
| Base Product Number | - |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
