DG534ADJ
lmages are for reference only.DG534ADJ
IC AMP/VIDEO/MUX LP 4/8CH 20DIP
Datasheet20-DIP (0.300", 7.62mm)
16,309 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Ultrasound, Video Switch IC 2 Channel 20-PDIP
DG534ADJ
| Category | Integrated Circuits (ICs) - Interface - Analog Switches Special Purpose |
| Manufacturer | Vishay Siliconix |
| Series | - |
| Packaging | Tube |
| RoHS Status | RoHS non-compliant |
| Applications | Ultrasound, Video |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Switch Circuit | SPDT |
| Number of Channels | 2 |
| On-State Resistance (Max) | 90Ohm |
| Voltage - Supply, Single (V+) | 10V ~ 21V |
| Voltage - Supply, Dual (V±) | - |
| -3db Bandwidth | 500MHz |
| Features | T-Switch Configuration |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 20-DIP (0.300", 7.62mm) |
| Supplier Device Package | 20-PDIP |
| Base Product Number | DG534 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | DG534ADJ-E3 | DG534ADN | DG534ADN-E3 | DG542AP |
| Manufacturer | Vishay Siliconix | Vishay Siliconix | Vishay Siliconix | Vishay Siliconix |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | IC AMP/VIDEO/MUX LP 4/8CH 20DIP | IC AMP/VIDEO/MUX LP 4/8CH 20PLCC | IC AMP/VIDEO/MUX LP 4/8CH 20PLCC | IC SWITCH QUAD SPST 16DIP |
| Series | - | - | - | - |
| Packaging | Bulk | Tube | Bulk | Tube |
