N-Channel 12 V 15A (Ta) 2.1W (Ta) Surface Mount U-DFN2020-6
DMN1004UFDF-13
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 12 V |
| Current - Continuous Drain (Id) @ 25°C | 15A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V, 4.5V |
| Rds On (Max) @ Id, Vgs | 4.8mOhm @ 15A, 4.5V |
| Vgs(th) (Max) @ Id | 1V @ 250µA |
| Vgs (Max) | ±8V |
| Input Capacitance (Ciss) (Max) @ Vds | 2385 pF @ 6 V |
| FET Feature | - |
| Power Dissipation (Max) | 2.1W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | U-DFN2020-6 |
| Package / Case | 6-UDFN Exposed Pad |
| Base Product Number | DMN1004 |
| Gate Charge (Qg) (Max) @ Vgs | 47 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
|
| Part Number | DMN1004UFDF-7 | DMN1004UFV-13 | DMN1004UFV-7 | DMN100-7-F |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 12V 15A 6UDFN | MOSFET N-CH 12V 70A POWERDI3333 | MOSFET N-CH 12V 70A POWERDI3333 | MOSFET N-CH 30V 1.1A SC59-3 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
