DMN1019UFDE-7
lmages are for reference only.DMN1019UFDE-7
MOSFET N CH 12V 11A U-DFN2020-6E
Datasheet6-PowerUDFN
49,381 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 12 V 11A (Ta) 690mW (Ta) Surface Mount U-DFN2020-6 (Type E)
DMN1019UFDE-7
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 12 V |
| Current - Continuous Drain (Id) @ 25°C | 11A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 1.2V, 4.5V |
| Rds On (Max) @ Id, Vgs | 10mOhm @ 9.7A, 4.5V |
| Vgs(th) (Max) @ Id | 800mV @ 250µA |
| Vgs (Max) | ±8V |
| Input Capacitance (Ciss) (Max) @ Vds | 2425 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 690mW (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | U-DFN2020-6 (Type E) |
| Package / Case | 6-PowerUDFN |
| Base Product Number | DMN1019 |
| Gate Charge (Qg) (Max) @ Vgs | 50.6 nC @ 8 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | DMN1019USN-13 | DMN1019USN-7 | DMN1019USNQ-13 | DMN1019USNQ-7 |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 12V 9.3A SC59 | MOSFET N-CH 12V 9.3A SC59 | MOSFET BVDSS: 8V~24V SC59 T&R 10 | MOSFET BVDSS: 8V~24V SC59 T&R 3K |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) |
