DMT10H009LCG-7
lmages are for reference only.DMT10H009LCG-7
MOSFET N-CH 100V 12.4A/47A 8DFN
Datasheet8-PowerVDFN
40,138 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 100 V 12.4A (Ta), 47A (Tc) 1W (Ta) Surface Mount V-DFN3333-8 (Type B)
DMT10H009LCG-7
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Diodes Incorporated |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 100 V |
| Current - Continuous Drain (Id) @ 25°C | 12.4A (Ta), 47A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 8.8mOhm @ 20A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 2309 pF @ 50 V |
| FET Feature | - |
| Power Dissipation (Max) | 1W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | V-DFN3333-8 (Type B) |
| Package / Case | 8-PowerVDFN |
| Base Product Number | DMT10 |
| Gate Charge (Qg) (Max) @ Vgs | 20.2 nC @ 4.5 V |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
 |
| Part Number | DMT10H003SPSW-13 | DMT10H009LFG-13 | DMT10H009LFG-7 | DMT10H009LH3 |
| Manufacturer | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated | Diodes Incorporated |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET BVDSS: 61V~100V POWERDI50 | MOSFET N-CH 100V 13A/50A PWRDI | MOSFET N-CH 100V 13A/50A PWRDI | MOSFET N-CH 100V 84A TO251 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tube |
