ECLAMP2342N.TCT
lmages are for reference only.ECLAMP2342N.TCT
FILTER RC(PI) 100 OHM/12PF SMD
Datasheet16-VFQFN Exposed Pad
31,778 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RC (Pi) EMI Filter 2nd Order Low Pass 8 Channel R = 100Ohms, C = 12pF (Total) 16-VFQFN Exposed Pad
ECLAMP2342N.TCT
| Category | Filters - EMI-RFI Filters LC-RC Networks - |
| Manufacturer | Semtech Corporation |
| Series | EClamp™ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | RoHS Compliant |
| Type | Low Pass |
| Filter Order | 2nd |
| Technology | RC (Pi) |
| Center / Cutoff Frequency | - |
| Attenuation Value | 30dB @ 1GHz ~ 2.5GHz |
| Resistance - Channel (Ohms) | 100 |
| Current | - |
| Values | R = 100Ohms, C = 12pF (Total) |
| ESD Protection | Yes |
| Operating Temperature | -40°C ~ 85°C |
| Applications | Data Lines for Mobile Devices |
| Voltage - Rated | - |
| Mounting Type | Surface Mount |
| Package / Case | 16-VFQFN Exposed Pad |
| Size / Dimension | 0.118" L x 0.118" W (3.00mm x 3.00mm) |
| Height | 0.039" (1.00mm) |
| Number of Channels | 8 |
| Base Product Number | ECLAMP2342 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | ECLAMP2342N.TCT | ECLAMP0501T.TCT | ECLAMP0501T.TCT | ECLAMP0504T.TCT |
| Manufacturer | Semtech Corporation | Semtech Corporation | Semtech Corporation | Semtech Corporation |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | FILTER RC(PI) 100 OHM/12PF SMD | FILTER RC 1 KOHM/12PF ESD SMD | FILTER RC 1 KOHM/12PF ESD SMD | FILTER RC 1 KOHM/12PF ESD SMD |
| Series | EClamp™ | EMIClamp® | EMIClamp® | EMIClamp® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
