EFM8SB20F64G-A-QFN32R
lmages are for reference only.EFM8SB20F64G-A-QFN32R
IC MCU 8BIT 64KB FLASH 32QFN
Datasheet32-VFQFN Exposed Pad
88,438 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
CIP-51 8051 Sleepy Bee Microcontroller IC 8-Bit 25MHz 64KB (64K x 8) FLASH 32-QFN (5x5)
EFM8SB20F64G-A-QFN32R
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Silicon Labs |
| Series | Sleepy Bee |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Core Processor | CIP-51 8051 |
| Core Size | 8-Bit |
| Speed | 25MHz |
| Connectivity | EBI/EMI, I2C, SMBus, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Number of I/O | 24 |
| Program Memory Size | 64KB (64K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 4.25K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
| Data Converters | A/D 23x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 32-QFN (5x5) |
| Package / Case | 32-VFQFN Exposed Pad |
| Base Product Number | EFM8SB20 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
|
 |
| Part Number | EFM8SB20F64G-A-QFN24 | EFM8SB20F64G-A-QFN24R | EFM8SB20F64G-A-QFN32 | EFM8SB20F64G-A-QFP32 |
| Manufacturer | Silicon Labs | Silicon Labs | Silicon Labs | Silicon Labs |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC MCU 8BIT 64KB FLASH 24QFN | IC MCU 8BIT 64KB FLASH 24QFN | IC MCU 8BIT 64KB FLASH 32QFN | IC MCU 8BIT 64KB FLASH 32QFP |
| Series | Silicon Labs | Silicon Labs | Silicon Labs | Silicon Labs |
| Packaging | Tube | Tape & Reel (TR) | Tube | Tray |
