2 Line Common Mode Choke Through Hole 800mA DCR 330mOhm (Typ)
ELF-11M080E
| Category | Filters - Common Mode Chokes - |
| Manufacturer | Panasonic Electronic Components |
| Series | M |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Filter Type | - |
| Number of Lines | 2 |
| Inductance @ Frequency | - |
| Current Rating (Max) | 800mA |
| DC Resistance (DCR) (Max) | 330mOhm (Typ) |
| Voltage Rating - DC | - |
| Voltage Rating - AC | - |
| Operating Temperature | - |
| Ratings | - |
| Approval Agency | - |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 0.630" L x 0.413" W (16.00mm x 10.50mm) |
| Height (Max) | 0.669" (17.00mm) |
| Package / Case | Vertical, 4 PC Pin |
| Base Product Number | ELF-11 |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ELF-11M010E | ELF-11M020E | ELF-11M030E | ELF-11M040E |
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | CMC 100MA 2LN TH | CMC 200MA 2LN TH | CMC 300MA 2LN TH | CMC 400MA 2LN TH |
| Series | M | M | M | M |
| Packaging | Bulk | Bulk | Bulk | Bulk |
