ESD201B203LRHE6327XTSA1
lmages are for reference only.ESD201B203LRHE6327XTSA1
TVS DIODE 5.5VWM 12.1VC TSLP-3
DatasheetSC-101, SOT-883
35,153 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
12.1V (Typ) Clamp 16A (8/20µs) Ipp Tvs Diode Surface Mount PG-TSLP-3
ESD201B203LRHE6327XTSA1
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Infineon Technologies |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | |
| Type | Zener |
| Bidirectional Channels | 2 |
| Voltage - Reverse Standoff (Typ) | 5.5V (Max) |
| Voltage - Breakdown (Min) | - |
| Voltage - Clamping (Max) @ Ipp | 12.1V (Typ) |
| Current - Peak Pulse (10/1000µs) | 16A (8/20µs) |
| Power - Peak Pulse | - |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | 5pF @ 1MHz |
| Operating Temperature | -55°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | SC-101, SOT-883 |
| Supplier Device Package | PG-TSLP-3 |
| Base Product Number | ESD201 |
| Unidirectional Channels | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | ESD0301BL | ESD0302L | ESD0302TL | ESD03B3Z |
| Manufacturer | MDD | MDD | MDD | Diotec Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | TVS DIODE 3.3VWM 12VC DFN1006 | TVS DIODE 3.3VWM 10VC DFN1006-3L | TVS DIODE 3.3VWM 10VC SOT23 | TVS DIODE 3.3VWM 9.5VC 0201 |
| Series | MDD | MDD | MDD | Diotec Semiconductor |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Bulk |
