ESD202B1CSP01005XTSA1
lmages are for reference only.ESD202B1CSP01005XTSA1
TVS DIODE 5.5VWM 12VC P/WLL-2-2
Datasheet01005 (0402 Metric)
29,947 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
12V (Typ) Clamp 3A (8/20µs) Ipp Tvs Diode Surface Mount P/PG-WLL-2-2
ESD202B1CSP01005XTSA1
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Infineon Technologies |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | 1 |
| Voltage - Reverse Standoff (Typ) | 5.5V (Max) |
| Voltage - Breakdown (Min) | 6V |
| Voltage - Clamping (Max) @ Ipp | 12V (Typ) |
| Current - Peak Pulse (10/1000µs) | 3A (8/20µs) |
| Power - Peak Pulse | 36W |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | 6.5pF @ 1MHz |
| Operating Temperature | -55°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 01005 (0402 Metric) |
| Supplier Device Package | P/PG-WLL-2-2 |
| Base Product Number | ESD202 |
| Unidirectional Channels | - |
| Grade | - |
| Qualification | - |
