ESDSBSLC3V3LB-TP
lmages are for reference only.ESDSBSLC3V3LB-TP
TVS DIODE 3.3VWM 7VC 2DFN
Datasheet0402 (1006 Metric)
80,933 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
7V Clamp 4A (8/20µs) Ipp Tvs Diode Surface Mount 2-DFN1006
ESDSBSLC3V3LB-TP
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Type | Zener |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 3.3V (Max) |
| Voltage - Breakdown (Min) | 7V |
| Voltage - Clamping (Max) @ Ipp | 7V |
| Current - Peak Pulse (10/1000µs) | 4A (8/20µs) |
| Power - Peak Pulse | 34W |
| Power Line Protection | Yes |
| Applications | General Purpose |
| Capacitance @ Frequency | 0.35pF @ 1MHz |
| Operating Temperature | -55°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 0402 (1006 Metric) |
| Supplier Device Package | 2-DFN1006 |
| Base Product Number | ESDSBSLC3 |
| Unidirectional Channels | 2 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
 |
|
| Part Number | ESDSBSLC3V3AE2-TP | ESDSBSLC18VAE2-TP | ESDSBSLC18VLB-TP | ESDSBSLC5V0AE2-TP |
| Manufacturer | Micro Commercial Co | Micro Commercial Co | Micro Commercial Co | Micro Commercial Co |
| RoHS Status | ||||
| Description | TVS DIODE 3.3VWM 8.5VC 0201 | TVS DIODE 18VWM 10VC 0201 | TVS DIODE 18.5VWM 10VC 2DFN | TVS DIODE 5VWM 10VC 0201 |
| Series | Micro Commercial Co | Micro Commercial Co | Micro Commercial Co | Micro Commercial Co |
| Packaging | Bulk | Bulk | Bulk | Bulk |
