FAN5646UC00X
lmages are for reference only.FAN5646UC00X
IC LED DRVR LIN PWM 20MA 4WLCSP
Datasheet4-UFBGA, WLCSP
51,352 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 1 Output Linear PWM Dimming 20mA 4-WLCSP (0.82x0.82)
FAN5646UC00X
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | Fairchild Semiconductor |
| Series | TinyWire™ |
| Packaging | Bulk |
| RoHS Status | |
| Type | Linear |
| Topology | - |
| Internal Switch(s) | Yes |
| Number of Outputs | 1 |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Output | - |
| Current - Output / Channel | 20mA |
| Frequency | - |
| Dimming | PWM |
| Applications | - |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 4-UFBGA, WLCSP |
| Supplier Device Package | 4-WLCSP (0.82x0.82) |
| Base Product Number | FAN5646 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | FAN5646UC00X | FAN5646UC01X | FAN5646UC01X | FAN5640S7X |
| Manufacturer | onsemi | Fairchild Semiconductor | onsemi | onsemi |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IC LED DRVR LIN PWM 20MA 4WLCSP | IC LED DRVR LIN PWM 20MA 4WLCSP | IC LED DRVR LIN PWM 20MA 4WLCSP | IC LED DRVR LINEAR PWM 25MA SC88 |
| Series | TinyWire™ | TinyWire™ | TinyWire™ | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
