FDMF2011
Manufacturer
onsemiDescription
IC HALF BRIDGE DRIVER 20A 36QFN
Datasheet
DatasheetPackage
36-PowerWFQFN
In Stock
66,160 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
FDMF2011
FDMF2011
lmages are for reference only.Payment Methods
Delivery Services
Half Bridge Driver DC Motors, General Purpose Power MOSFET 36-PQFN (7.5x6)
Quick Inquiry
FDMF2011
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - Full Half-Bridge H Bridge Drivers |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Half Bridge |
| Applications | DC Motors, General Purpose |
| Interface | PWM |
| Load Type | Inductive, Capacitive |
| Technology | Power MOSFET |
| Rds On (Typ) | 7.3mOhm LS, 7.7mOhm HS |
| Current - Output / Channel | 20A |
| Current - Peak Output | - |
| Voltage - Supply | 10V ~ 20V |
| Voltage - Load | 3V ~ 80V |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Features | Bootstrap Circuit |
| Fault Protection | UVLO |
| Mounting Type | Surface Mount |
| Package / Case | 36-PowerWFQFN |
| Supplier Device Package | 36-PQFN (7.5x6) |
| Base Product Number | FDMF2011 |
| Grade | - |
| Qualification | - |
