Product CatalogPart Number
FDZ7064AS
Manufacturer
Fairchild SemiconductorDescription
MOSFET N-CH 30V 13.5A 30BGA
Datasheet
DatasheetPackage
30-WFBGA
In Stock
59,785 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
FDZ7064AS
FDZ7064AS
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 30 V 13.5A (Ta) 2.2W (Ta) Surface Mount 30-BGA (4x3.5)
Quick Inquiry
FDZ7064AS
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Fairchild Semiconductor |
| Series | PowerTrench® |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 13.5A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 5.6mOhm @ 13.5A, 10V |
| Vgs(th) (Max) @ Id | 3V @ 1mA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 1960 pF @ 15 V |
| FET Feature | - |
| Power Dissipation (Max) | 2.2W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 30-BGA (4x3.5) |
| Package / Case | 30-WFBGA |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 51 nC @ 10 V |
| Grade | - |
| Qualification | - |
