FQPF10N20C
Manufacturer
onsemiDescription
MOSFET N-CH 200V 9.5A TO220F
Datasheet
DatasheetPackage
TO-220-3 Full Pack
In Stock
86,792 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
FQPF10N20C
FQPF10N20C
lmages are for reference only.Payment Methods
Delivery Services
N-Channel 200 V 9.5A (Tc) 38W (Tc) Through Hole TO-220F-3
Quick Inquiry
FQPF10N20C
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | onsemi |
| Series | QFET® |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 200 V |
| Current - Continuous Drain (Id) @ 25°C | 9.5A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Rds On (Max) @ Id, Vgs | 360mOhm @ 4.75A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Vgs (Max) | ±30V |
| Input Capacitance (Ciss) (Max) @ Vds | 510 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 38W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-220F-3 |
| Package / Case | TO-220-3 Full Pack |
| Base Product Number | FQPF10 |
| Gate Charge (Qg) (Max) @ Vgs | 26 nC @ 10 V |
| Grade | - |
| Qualification | - |
