Product CatalogPart Number
GSID100A120S5C1
Manufacturer
SemiQDescription
IGBT MOD 1200V 170A 650W
Datasheet
DatasheetPackage
Module
In Stock
17,143 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
GSID100A120S5C1
GSID100A120S5C1
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module Three Phase Inverter 1200 V 170 A 650 W Chassis Mount Module
Quick Inquiry
GSID100A120S5C1
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | SemiQ |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | - |
| Configuration | Three Phase Inverter |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 170 A |
| Power - Max | 650 W |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 100A |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 13.7 nF @ 25 V |
| Input | Standard |
| NTC Thermistor | Yes |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Supplier Device Package | Module |
| Base Product Number | GSID100 |
