Product CatalogPart Number
GSID100A120T2C1A
Manufacturer
SemiQDescription
IGBT MOD 1200V 200A 800W
Datasheet
DatasheetPackage
Module
In Stock
26,166 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
GSID100A120T2C1A
GSID100A120T2C1A
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module Three Phase Inverter 1200 V 200 A 800 W Chassis Mount Module
Quick Inquiry
GSID100A120T2C1A
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | SemiQ |
| Series | Amp+™ |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | - |
| Configuration | Three Phase Inverter |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 200 A |
| Power - Max | 800 W |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 100A |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 13.7 nF @ 25 V |
| Input | Three Phase Bridge Rectifier |
| NTC Thermistor | Yes |
| Operating Temperature | -40°C ~ 150°C |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Supplier Device Package | Module |
| Base Product Number | GSID100 |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | GSID100A120S5C1 | GSID100A120T2C1 | GA200SA60S | GSA75AA120 |
| Manufacturer | SemiQ | SemiQ | Vishay General Semiconductor - Diodes Division | SanRex Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant | ROHS3 Compliant |
| Description | IGBT MOD 1200V 170A 650W | IGBT MOD 1200V 200A 640W | IGBT MOD 600V 200A 630W SOT227B | IGBT MODULE 75A SINGLE 1200V HIG |
| Series | - | Amp+™ | - | - |
| Packaging | Bulk | Bulk | Tube |
