HGT1S20N60B3S
lmages are for reference only.HGT1S20N60B3S
40A, 600V, UFS N-CHANNEL IGBT
DatasheetTO-263-3, D2PAK (2 Leads + Tab), TO-263AB
43,814 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT 600 V 40 A Surface Mount TO-263AB
HGT1S20N60B3S
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Harris Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| IGBT Type | - |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 40 A |
| Current - Collector Pulsed (Icm) | - |
| Vce(on) (Max) @ Vge, Ic | - |
| Power - Max | - |
| Switching Energy | - |
| Input Type | Standard |
| Gate Charge | - |
| Td (on/off) @ 25°C | - |
| Test Condition | - |
| Operating Temperature | - |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Supplier Device Package | TO-263AB |
| Reverse Recovery Time (trr) | - |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | HGT1S20N60A4S9A | HGT1S20N60C3R | HGT1S20N60C3S9A | HGT1S20N35F3VLR4505 |
| Manufacturer | onsemi | Harris Corporation | onsemi | Harris Corporation |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | Not applicable | |
| Description | IGBT 600V 70A 290W TO263AB | 40A, 600V, RUGGED N-CHANNEL IGBT | IGBT 600V 45A TO263AB | 40A, 350V, UFS N-CHANNEL IGBT |
| Series | - | - | - | * |
| Packaging | Tube | Bulk | Tape & Reel (TR) | Bulk |
