HGT1S20N60C3S9A
lmages are for reference only.Payment Methods
Delivery Services
IGBT 600 V 45 A 164 W Surface Mount TO-263 (D2PAK)
HGT1S20N60C3S9A
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | onsemi |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | - |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 45 A |
| Current - Collector Pulsed (Icm) | 300 A |
| Vce(on) (Max) @ Vge, Ic | 1.8V @ 15V, 20A |
| Power - Max | 164 W |
| Switching Energy | 295µJ (on), 500µJ (off) |
| Input Type | Standard |
| Gate Charge | 91 nC |
| Td (on/off) @ 25°C | 28ns/151ns |
| Test Condition | 480V, 20A, 10Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Supplier Device Package | TO-263 (D2PAK) |
| Reverse Recovery Time (trr) | - |
| Base Product Number | HGT1S20 |
| Product Attribute |  |
 |
 |
 |
| Part Number | HGT1S20N60A4S9A | HGT1S20N60B3S | HGT1S20N60C3R | HGT1S10N120BNS |
| Manufacturer | onsemi | Harris Corporation | Harris Corporation | onsemi |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | |
| Description | IGBT 600V 70A 290W TO263AB | 40A, 600V, UFS N-CHANNEL IGBT | 40A, 600V, RUGGED N-CHANNEL IGBT | IGBT 1200V 35A 298W TO263AB |
| Series | - | - | - | - |
| Packaging | Tube | Bulk | Bulk | Tube |
