HGTD3N60A4S
lmages are for reference only.HGTD3N60A4S
IGBT, 17A, 600V, N-CHANNEL
DatasheetTO-252-3, DPAK (2 Leads + Tab), SC-63
68,396 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT 600 V 17 A 70 W Surface Mount TO-252 (DPAK)
HGTD3N60A4S
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Fairchild Semiconductor |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | - |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 17 A |
| Current - Collector Pulsed (Icm) | 40 A |
| Vce(on) (Max) @ Vge, Ic | 2.7V @ 15V, 3A |
| Power - Max | 70 W |
| Switching Energy | - |
| Input Type | Standard |
| Gate Charge | 32 nC |
| Td (on/off) @ 25°C | 6ns/73ns |
| Test Condition | 390V, 3A, 50Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Supplier Device Package | TO-252 (DPAK) |
| Reverse Recovery Time (trr) | - |
| Base Product Number | - |
| Product Attribute |  |
|
|
 |
| Part Number | HGTD3N60B3 | HGTD3N60B3S | HGTD3N60B3S9A | HGTD3N60C3 |
| Manufacturer | Harris Corporation | Harris Corporation | Harris Corporation | Harris Corporation |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | Not applicable |
| Description | IGBT 600V 7A IPAK | 7A, 600V, UFS N-CHANNEL IGBT | 7A, 600V, UFS N-CHANNEL IGBT | IGBT 600V 6A IPAK |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
