HGTD3N60B3
lmages are for reference only.HGTD3N60B3
IGBT 600V 7A IPAK
DatasheetTO-251-3 Short Leads, IPAK, TO-251AA
24,276 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT 600 V 7 A 33.3 W Through Hole IPAK
HGTD3N60B3
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Harris Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| IGBT Type | - |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 7 A |
| Current - Collector Pulsed (Icm) | 20 A |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 3.5A |
| Power - Max | 33.3 W |
| Switching Energy | 66µJ (on), 88µJ (off) |
| Input Type | Standard |
| Gate Charge | 21 nC |
| Td (on/off) @ 25°C | 18ns/105ns |
| Test Condition | 480V, 3.5A, 82Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-251-3 Short Leads, IPAK, TO-251AA |
| Supplier Device Package | IPAK |
| Reverse Recovery Time (trr) | 16 ns |
| Base Product Number | - |
| Product Attribute | |
|
 |
 |
| Part Number | HGTD3N60B3S | HGTD3N60B3S9A | HGTD3N60A4S | HGTD3N60C3 |
| Manufacturer | Harris Corporation | Harris Corporation | Fairchild Semiconductor | Harris Corporation |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | Not applicable |
| Description | 7A, 600V, UFS N-CHANNEL IGBT | 7A, 600V, UFS N-CHANNEL IGBT | IGBT, 17A, 600V, N-CHANNEL | IGBT 600V 6A IPAK |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
