HGTD7N60B3S
lmages are for reference only.HGTD7N60B3S
14A, 600V, UFS N-CHANNEL IGBT
DatasheetTO-252-3, DPAK (2 Leads + Tab), SC-63
73,805 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT 600 V 14 A 60 W Surface Mount TO-252AA
HGTD7N60B3S
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Harris Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| IGBT Type | - |
| Voltage - Collector Emitter Breakdown (Max) | 600 V |
| Current - Collector (Ic) (Max) | 14 A |
| Current - Collector Pulsed (Icm) | 56 A |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 7A |
| Power - Max | 60 W |
| Switching Energy | 72µJ (on), 120µJ (off) |
| Input Type | Standard |
| Gate Charge | 37 nC |
| Td (on/off) @ 25°C | 26ns/130ns |
| Test Condition | 480V, 7A, 50Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Supplier Device Package | TO-252AA |
| Reverse Recovery Time (trr) | - |
| Base Product Number | - |
| Product Attribute | |
 |
|
 |
| Part Number | HGTD7N60B3 | HGTD7N60C3S9A | HGTD7N60C3S9A | HGT1S20N60C3S9A |
| Manufacturer | Harris Corporation | onsemi | Fairchild Semiconductor | onsemi |
| RoHS Status | RoHS non-compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IGBT 600V 14A IPAK | IGBT 600V 14A TO252AA | INSULATED GATE BIPOLAR TRANSISTO | IGBT 600V 45A TO263AB |
| Series | - | - | - | - |
| Packaging | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Bulk | Tape & Reel (TR) |
