HSMF-C146
Manufacturer
Broadcom LimitedDescription
LED BLUE/RED CLEAR SMD R/A
Datasheet
DatasheetPackage
4-SMD
In Stock
94,657 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
HSMF-C146
HSMF-C146
lmages are for reference only.Payment Methods
Delivery Services
Blue, Red 464nm Blue, 632nm Red LED Indication - Discrete 3.4V Blue, 2.3V Red 4-SMD
Quick Inquiry
HSMF-C146
Specifications
| Category | Optoelectronics - LED Indication Discrete - |
| Manufacturer | Broadcom Limited |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Color | Blue, Red |
| Configuration | Common Anode |
| Lens Color | Colorless |
| Lens Transparency | Clear |
| Millicandela Rating | 75mcd Blue, 79mcd Red |
| Lens Style | Rectangle with Domed Top |
| Lens Size | 2.00mm x 1.00mm |
| Voltage - Forward (Vf) (Typ) | 3.4V Blue, 2.3V Red |
| Current - Test | 20mA Blue, 20mA Red |
| Viewing Angle | 120° |
| Mounting Type | Surface Mount, Right Angle |
| Wavelength - Dominant | 464nm Blue, 632nm Red |
| Wavelength - Peak | 459nm Blue, 644nm Red |
| Features | - |
| Package / Case | 4-SMD |
| Supplier Device Package | SMD |
| Size / Dimension | 3.00mm L x 2.00mm W |
| Height (Max) | 1.10mm |
| Base Product Number | HSMF-C146 |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | HSMF-C142 | HSMF-C143 | HSMF-C144 | HSMF-C145 |
| Manufacturer | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | LED GREEN/RED SMD R/A | LED AMBER/GREEN CLEAR SMD R/A | LED GREEN/RED CLEAR SMD R/A | LED GREEN/RED CLEAR SMD R/A |
| Series | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
