HV1812Y472KXHATHV
lmages are for reference only.HV1812Y472KXHATHV
CAP CER 4700PF 3KV X7R 1812
Datasheet1812 (4532 Metric)
31,549 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
4700 pF ±10% 3000V (3kV) Ceramic Capacitor X7R 1812 (4532 Metric)
HV1812Y472KXHATHV
| Category | Capacitors - Ceramic Capacitors - |
| Manufacturer | Vishay Vitramon |
| Series | HV |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 4700 pF |
| Tolerance | ±10% |
| Voltage - Rated | 3000V (3kV) |
| Temperature Coefficient | X7R |
| Operating Temperature | -55°C ~ 125°C |
| Features | High Voltage |
| Ratings | - |
| Applications | General Purpose |
| Failure Rate | - |
| Mounting Type | Surface Mount, MLCC |
| Package / Case | 1812 (4532 Metric) |
| Size / Dimension | 0.177" L x 0.126" W (4.50mm x 3.20mm) |
| Height - Seated (Max) | - |
| Thickness (Max) | 0.126" (3.20mm) |
| Lead Spacing | - |
| Lead Style | - |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | HV1812Y472KBHARHV | HV1812Y472KBHATHV | HV1812Y472KXHARHV | HV1812Y102JXHARHV |
| Manufacturer | Vishay Vitramon | Vishay Vitramon | Vishay Vitramon | Vishay Vitramon |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP CER 4700PF 3KV X7R 1812 | CAP CER 4700PF 3KV X7R 1812 | CAP CER 4700PF 3KV X7R 1812 | CAP CER 1000PF 3KV X7R 1812 |
| Series | Vishay Vitramon | Vishay Vitramon | Vishay Vitramon | Vishay Vitramon |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
