ILD610-2X007T
lmages are for reference only.ILD610-2X007T
OPTOISO 5.3KV 2CH TRANS 8SMD
Datasheet8-SMD, Gull Wing
75,383 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Optoisolator Transistor Output 5300Vrms 2 Channel 8-SMD
ILD610-2X007T
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | Vishay Semiconductor Opto Division |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Number of Channels | 2 |
| Voltage - Isolation | 5300Vrms |
| Current Transfer Ratio (Min) | 63% @ 10mA |
| Current Transfer Ratio (Max) | 125% @ 10mA |
| Turn On / Turn Off Time (Typ) | 3.2µs, 3.4µs |
| Rise / Fall Time (Typ) | 2.5µs, 2.6µs |
| Input Type | DC |
| Output Type | Transistor |
| Voltage - Output (Max) | 70V |
| Current - Output / Channel | 50mA |
| Voltage - Forward (Vf) (Typ) | 1.25V |
| Current - DC Forward (If) (Max) | 60 mA |
| Vce Saturation (Max) | 400mV |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD, Gull Wing |
| Supplier Device Package | 8-SMD |
| Base Product Number | ILD610 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
|
| Part Number | ILD610-1 | ILD610-3 | ILD1 | ILD1 |
| Manufacturer | Vishay Semiconductor Opto Division | Vishay Semiconductor Opto Division | Isocom Components 2004 LTD | Vishay Semiconductor Opto Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | OPTOISO 5.3KV 2CH TRANS 8DIP | OPTOISO 5.3KV 2CH TRANS 8DIP | 8PIN TRANSISTOR DETECTOR, HIGH D | OPTOISOLTR 5.3KV 2CH TRANS 8-DIP |
| Series | - | - | ILD | - |
| Packaging | Tube | Tube | Tube | Tube |
