IGBT 390 V 46 A 250 W Surface Mount TO-263 (D2PAK)
ISL9V5036S3ST_SB82170
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | onsemi |
| Series | EcoSPARK® |
| Packaging | Bulk |
| RoHS Status | |
| IGBT Type | - |
| Voltage - Collector Emitter Breakdown (Max) | 390 V |
| Current - Collector (Ic) (Max) | 46 A |
| Current - Collector Pulsed (Icm) | - |
| Vce(on) (Max) @ Vge, Ic | 1.6V @ 4V, 10A |
| Power - Max | 250 W |
| Switching Energy | - |
| Input Type | Logic |
| Gate Charge | 32 nC |
| Td (on/off) @ 25°C | -/10.8µs |
| Test Condition | 300V, 1kOhm, 5V |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Supplier Device Package | TO-263 (D2PAK) |
| Reverse Recovery Time (trr) | - |
| Base Product Number | ISL9 |
| Product Attribute |  |
 |
|
 |
| Part Number | ISL9V5036S3ST_SB82026C | ISL9V5036S3 | ISL9V5036S3S | ISL9V5036S3ST |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | ROHS3 Compliant | |||
| Description | INTEGRATED CIRCUIT | IGBT 390V 46A 250W TO262AA | IGBT 390V 46A 250W TO263AB | IGBT 390V 46A 250W TO263AB |
| Series | EcoSPARK® | EcoSPARK® | EcoSPARK® | EcoSPARK® |
| Packaging | Bulk | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) |
