General Purpose Relay SPDT (1 Form C) Through Hole
J1MACD-26XLS
| Category | Relays - Signal Relays-Up to 2 Amps - |
| Manufacturer | TE Connectivity Aerospace, Defense and Marine |
| Series | 1MA, CII |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Mounting Type | Through Hole |
| Coil Voltage | 26.5VDC |
| Contact Form | SPDT (1 Form C) |
| Contact Rating (Current) | 1 A |
| Switching Voltage | 115VAC, 28VDC - Max |
| Load - Max Switching | 115VA, 28W |
| Coil Type | Non Latching |
| Features | Diode |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Hermetically |
| Coil Insulation | - |
| Must Operate Voltage | 14.2 VDC |
| Must Release Voltage | 1.37 VDC |
| Operate Time | 2 ms |
| Release Time | 4 ms |
| Operating Temperature | -65°C ~ 125°C |
| Contact Material | Silver Palladium (AgPd), Gold (Au) |
| Approval Agency | - |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Base Product Number | J1MAC |
| Coil Current | 13.3 mA |
| Coil Resistance | 2 kOhms |
| Product Attribute | |
 |
 |
|
| Part Number | J1MACD-26X | J1MACD-26XM | J1MACD-26XMS | J1MACD-26XP |
| Manufacturer | TE Connectivity | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine | TE Connectivity Aerospace, Defense and Marine |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | RoHS non-compliant |
| Description | RELAY | RELAY GEN PURPOSE SPDT 1A 26.5V | RELAY GEN PURPOSE SPDT 1A 26.5V | RELAY GEN PURPOSE SPDT 1A 26.5V |
| Series | * | 1MAD, CII | 1MAD, CII | 1MA, CII |
| Packaging | Bulk | Bulk | Bulk | Bulk |
