Product CatalogPart Number
JAN2N697S
Manufacturer
Microchip TechnologyDescription
TRANS NPN 40V TO39
Datasheet
DatasheetPackage
TO-205AD, TO-39-3 Metal Can
In Stock
81,433 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
JAN2N697S
JAN2N697S
lmages are for reference only.Payment Methods
Delivery Services
Bipolar (BJT) Transistor NPN 40 V 600 mW Through Hole TO-39 (TO-205AD)
Quick Inquiry
JAN2N697S
Specifications
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Transistor Type | NPN |
| Current - Collector (Ic) (Max) | - |
| Voltage - Collector Emitter Breakdown (Max) | 40 V |
| Vce Saturation (Max) @ Ib, Ic | 1.5V @ 15mA, 150mA |
| Current - Collector Cutoff (Max) | 10µA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 40 @ 150mA, 10V |
| Power - Max | 600 mW |
| Frequency - Transition | - |
| Operating Temperature | -65°C ~ 200°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-205AD, TO-39-3 Metal Can |
| Supplier Device Package | TO-39 (TO-205AD) |
| Base Product Number | - |
| Grade | Military |
| Qualification | MIL-PRF-19500/99 |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
|
| Part Number | JAN2N697 | JAN2N6032 | JAN2N6033 | JAN2N6051 |
| Manufacturer | Microchip Technology | Microchip Technology | Microchip Technology | Microchip Technology |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | TRANS NPN 40V TO5 | TRANS NPN 90V 50A TO-3 | TRANS NPN 120V 40A TO-3 | TRANS PNP DARL 80V 12A TO3 |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Bulk |
