KTD3133EUS-TR
lmages are for reference only.KTD3133EUS-TR
2-CHANNEL HIGH EFFICIENCY LED DR
Datasheet12-WFBGA, WLCSP
89,490 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 2 Output DC DC Regulator Step-Up (Boost) I2C, PWM Dimming 29.8mA 12-WLCSP (1.19x1.64)
KTD3133EUS-TR
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | Kinetic Technologies |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Type | DC DC Regulator |
| Topology | Step-Up (Boost) |
| Internal Switch(s) | - |
| Number of Outputs | 2 |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Output | - |
| Current - Output / Channel | 29.8mA |
| Frequency | 500kHz, 1MHz |
| Dimming | I2C, PWM |
| Applications | Backlight |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 12-WFBGA, WLCSP |
| Supplier Device Package | 12-WLCSP (1.19x1.64) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | KTD2026BEWE-TR | KTD2026CEWE-TR | KTD2026EWE-TR | KTD2027EWE-TR |
| Manufacturer | Kinetic Technologies | Kinetic Technologies | Kinetic Technologies | Kinetic Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 3-CHANNEL RGB LED DRIVER WITH I2 | 3-CHANNEL RGB LED DRIVER WITH I2 | 3-CHANNEL RGB LED DRIVER WITH I2 | 4-CHANNEL RGB LED DRIVER WITH I2 |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
