KTD3156BEFJ-TR
lmages are for reference only.KTD3156BEFJ-TR
6P10S LED DRIVER WITH PWM-CONTRO
Datasheet16-VFQFN Exposed Pad
32,265 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 6 Output DC DC Regulator Step-Up (Boost) Analog, PWM Dimming 30mA 16-TQFN (3x3)
KTD3156BEFJ-TR
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | Kinetic Technologies |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | DC DC Regulator |
| Topology | Step-Up (Boost) |
| Internal Switch(s) | - |
| Number of Outputs | 6 |
| Voltage - Supply (Min) | 2.7V |
| Voltage - Supply (Max) | 5.5V |
| Voltage - Output | - |
| Current - Output / Channel | 30mA |
| Frequency | 1MHz |
| Dimming | Analog, PWM |
| Applications | Backlight |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-VFQFN Exposed Pad |
| Supplier Device Package | 16-TQFN (3x3) |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | KTD3116EAA-20-1-TR | KTD3117EAA-20-1-TR | KTD3118EAA-25-TR | KTD3119EAA-25-TR |
| Manufacturer | Kinetic Technologies | Kinetic Technologies | Kinetic Technologies | Kinetic Technologies |
| RoHS Status | ||||
| Description | 2-CHANNEL LED DRIVER WITH BOOST | 3-CHANNEL LED DRIVER WITH BOOST | 2-CHANNEL LED DRIVER WITH BOOST | 2-CHANNEL LED DRIVER WITH BOOST |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
