LDD-F5404RI
lmages are for reference only.LDD-F5404RI
DISP 14SEG 0.54" DBL RED 18DIP
Datasheet18-DIP (0.600", 15.24mm)
77,922 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Display Modules - LED Character and Numeric Red 14-Segment, Alphanumeric 2 Character Common Cathode 2V 10mA 0.827" H x 0.984" W x 0.307" D (21.00mm x 25.00mm x 7.80mm) 18-DIP (0.600", 15.24mm)
LDD-F5404RI
| Category | Optoelectronics - LED Character and Numeric - |
| Manufacturer | Lumex Opto/Components Inc. |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Number of Characters | 2 |
| Size / Dimension | 0.827" H x 0.984" W x 0.307" D (21.00mm x 25.00mm x 7.80mm) |
| Digit/Alpha Size | 0.54" (13.72mm) |
| Display Type | 14-Segment, Alphanumeric |
| Common Pin | Common Cathode |
| Color | Red |
| Voltage - Forward (Vf) (Typ) | 2V |
| Current - Test | 10mA |
| Millicandela Rating | 2mcd |
| Wavelength - Peak | 635nm |
| Power Dissipation (Max) | 105mW |
| Package / Case | 18-DIP (0.600", 15.24mm) |
| Base Product Number | LDD-F5404 |
| Display Format | - |
| Product Attribute | |
|
|
 |
| Part Number | LDD-F5403RI | LDD-F5406RI | LDD-F2802RI | LDD-F302NI |
| Manufacturer | Lumex Opto/Components Inc. | Lumex Opto/Components Inc. | Lumex Opto/Components Inc. | Lumex Opto/Components Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DISP 14SEG 0.54" DBL YLW 18DIP | DISP 14SEG 0.54" DBL RED 18DIP | DISPLAY 7SEG 0.28" DBL GRN 10DIP | DISPLAY 7SEG 0.3" DBL GRN 10DIP |
| Series | - | - | - | - |
| Packaging | Bulk | Bulk | Bulk | Tube |
