LFTVXO075805REEL
lmages are for reference only.LFTVXO075805REEL
XTAL OSC VCTCXO 16.3840MHZ SNWV
Datasheet4-SMD, No Lead
53,201 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
16.384 MHz VCTCXO Clipped Sine Wave Oscillator 3.3V 4-SMD, No Lead
LFTVXO075805REEL
| Category | Crystals, Oscillators, Resonators - Oscillators - |
| Manufacturer | IQD Frequency Products |
| Series | IQXT-220-2 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Base Resonator | Crystal |
| Type | VCTCXO |
| Frequency | 16.384 MHz |
| Function | - |
| Output | Clipped Sine Wave |
| Voltage - Supply | 3.3V |
| Frequency Stability | ±280ppb |
| Absolute Pull Range (APR) | - |
| Operating Temperature | -40°C ~ 85°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 5mA |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
| Height - Seated (Max) | 0.039" (1.00mm) |
| Base Product Number | - |
| Product Attribute |  |
|
 |
 |
| Part Number | LFTVXO075802REEL | LFTVXO075803REEL | LFTVXO075804REEL | LFTVXO075806 |
| Manufacturer | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | XTAL OSC VCTCXO 10.0000MHZ SNWV | XTAL OSC VCTCXO 12.8000MHZ SNWV | XTAL OSC VCTCXO 16.3200MHZ SNWV | XTAL OSC VCTCXO 19.2000MHZ SNWV |
| Series | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products | IQD Frequency Products |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
