MAL211844103E3
lmages are for reference only.MAL211844103E3
CAP ALUM 10000UF 20% 10V TH
DatasheetRadial, Can - Mounting Ring - 4 Lead
64,959 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
10000 µF 10 V Aluminum Electrolytic Capacitors Radial, Can - Mounting Ring - 4 Lead 84mOhm @ 100Hz 8000 Hrs @ 125°C
MAL211844103E3
| Category | Capacitors - Aluminum Electrolytic Capacitors - |
| Manufacturer | Vishay Beyschlag/Draloric/BC Components |
| Series | 118 AHT |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Capacitance | 10000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 10 V |
| ESR (Equivalent Series Resistance) | 84mOhm @ 100Hz |
| Lifetime @ Temp. | 8000 Hrs @ 125°C |
| Operating Temperature | -55°C ~ 125°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 1.86 A @ 100 Hz |
| Ripple Current @ High Frequency | - |
| Lead Spacing | - |
| Size / Dimension | 0.827" Dia (21.00mm) |
| Height - Seated (Max) | - |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Mounting Ring - 4 Lead |
| Base Product Number | - |
| Impedance | 100 mOhms |
| Product Attribute | |
 |
|
 |
| Part Number | MAL211844103E3 | MAL211844332E3 | MAL211844332E3 | MAL211844472E3 |
| Manufacturer | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CAP ALUM 10000UF 20% 10V TH | CAP ALUM 3300UF 20% 10V TH | CAP ALUM 3300UF 20% 10V TH | CAP ALUM 4700UF 20% 10V TH |
| Series | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components | Vishay Beyschlag/Draloric/BC Components |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
