MCAC115P02-TP
Manufacturer
Micro Commercial CoDescription
MOSFET P-CH 20 115A DFN5060
Datasheet
DatasheetPackage
8-PowerTDFN
In Stock
31,884 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
MCAC115P02-TP
MCAC115P02-TP
lmages are for reference only.Payment Methods
Delivery Services
P-Channel 20 V 115A (Tc) 83.3W (Tj) Surface Mount DFN5060
Quick Inquiry
MCAC115P02-TP
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 20 V |
| Current - Continuous Drain (Id) @ 25°C | 115A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 3.2mOhm @ 57.5A, 10V |
| Vgs(th) (Max) @ Id | 900mV @ 250µA |
| Vgs (Max) | ±10V |
| Input Capacitance (Ciss) (Max) @ Vds | 5830 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 83.3W (Tj) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | DFN5060 |
| Package / Case | 8-PowerTDFN |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 221 nC @ 10 V |
| Grade | - |
| Qualification | - |
