MINISMDC035-2
lmages are for reference only.MINISMDC035-2
PTC RESET FUSE 6V 350MA 1210
Datasheet1210 (3225 Metric), Concave
96,750 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
PTC Resettable Fuse 6V 350 mA Ih Surface Mount 1210 (3225 Metric), Concave
MINISMDC035-2
| Category | Circuit Protection - PTC Resettable Fuses - |
| Manufacturer | Littelfuse Inc. |
| Series | PolySwitch®, miniSMD |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | RoHS non-compliant |
| Type | - |
| Voltage - Max | 6V |
| Current - Hold (Ih) (Max) | 350 mA |
| Current - Trip (It) | 700 mA |
| Current - Max | 40 A |
| Resistance - 25°C (Typ) | - |
| Operating Temperature | -40°C ~ 85°C |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 1210 (3225 Metric), Concave |
| Size / Dimension | 0.127" L x 0.102" W (3.22mm x 2.58mm) |
| Height - Seated (Max) | - |
| Thickness (Max) | 0.024" (0.62mm) |
| Lead Spacing | - |
| Approval Agency | - |
| Time to Trip | 0.1 s |
| Resistance - Initial (Ri) (Min) | 320 mOhms |
| Resistance - Post Trip (R1) (Max) | 1.3 Ohms |
| Grade | - |
| Qualification | - |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MINISMDC030F-2 | MINISMD050-2 | MINISMD075-2 | MINISMDC010-02 |
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | PTC RESET FUSE 30V 300MA 1812 | PTC RESET FUSE 500MA 1812 | PTC RESET FUSE 750MA 1812 | PTC RESET FUSE 60V 100MA 1812 |
| Series | PolySwitch®, miniSMD | PolySwitch® | PolySwitch® | PolySwitch®, miniSMD |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT)--> | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
