MIP50R12E2ATN-BP
Manufacturer
Micro Commercial CoDescription
IGBT MODULES 1200V 50A, E2A
Datasheet
DatasheetPackage
Module
In Stock
73,931 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
MIP50R12E2ATN-BP
MIP50R12E2ATN-BP
lmages are for reference only.Payment Methods
Delivery Services
IGBT Module Three Phase Inverter 1200 V 50 A 288 W Chassis Mount E2A
Quick Inquiry
MIP50R12E2ATN-BP
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Micro Commercial Co |
| Series | - |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | - |
| Configuration | Three Phase Inverter |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 50 A |
| Power - Max | 288 W |
| Vce(on) (Max) @ Vge, Ic | 2.3V @ 15V, 50A |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 2.6 nF @ 25 V |
| Input | Three Phase Bridge Rectifier |
| NTC Thermistor | Yes |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Supplier Device Package | E2A |
| Base Product Number | MIP50 |
