MMIX1Y82N120C3H1
Manufacturer
IXYSDescription
DISC IGBT SMPD PKG-STANDARD SMPD
Datasheet
DatasheetPackage
24-PowerSMD, 21 Leads
In Stock
69,414 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
MMIX1Y82N120C3H1
MMIX1Y82N120C3H1
lmages are for reference only.Payment Methods
Delivery Services
IGBT PT 1200 V 78 A 320 W Surface Mount 24-SMPD
Quick Inquiry
MMIX1Y82N120C3H1
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | IXYS |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | PT |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 78 A |
| Current - Collector Pulsed (Icm) | 320 A |
| Vce(on) (Max) @ Vge, Ic | 3.4V @ 15V, 82A |
| Power - Max | 320 W |
| Switching Energy | 4.95mJ (on), 2.78mJ (off) |
| Input Type | Standard |
| Gate Charge | 215 nC |
| Td (on/off) @ 25°C | 29ns/192ns |
| Test Condition | 600V, 80A, 2Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 24-PowerSMD, 21 Leads |
| Supplier Device Package | 24-SMPD |
| Reverse Recovery Time (trr) | 78 ns |
| Base Product Number | MMIX1Y82 |
