MP3398AGY-Z
lmages are for reference only.MP3398AGY-Z
IC LED DRV CTRL PWM 350MA 20SOIC
Datasheet20-SOIC (0.295", 7.50mm Width)
83,306 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
LED Driver IC 4 Output DC DC Controller Step-Up (Boost) Analog, PWM Dimming 350mA 20-SOIC
MP3398AGY-Z
| Category | Integrated Circuits (ICs) - Power Management PMIC - LED Drivers |
| Manufacturer | Monolithic Power Systems Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | DC DC Controller |
| Topology | Step-Up (Boost) |
| Internal Switch(s) | No |
| Number of Outputs | 4 |
| Voltage - Supply (Min) | 5V |
| Voltage - Supply (Max) | 28V |
| Voltage - Output | - |
| Current - Output / Channel | 350mA |
| Frequency | 540kHz |
| Dimming | Analog, PWM |
| Applications | Backlight |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 20-SOIC |
| Base Product Number | MP3398 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | MP3398AGY-P | MP3398AGF | MP3398AGF-P | MP3398AGF-Z |
| Manufacturer | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. | Monolithic Power Systems Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 4-CHANNEL(350MA EACH)BOOST WLED | IC LED DRVR CTRLR PWM 16TSSOP | 4-CHANNEL(350MA EACH)BOOST WLED | IC LED DRVR CTRLR PWM 16TSSOP |
| Series | MP | - | MP | - |
| Packaging | Tape & Reel (TR) | Tube | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
