NJM2845DL1-23-TE1
lmages are for reference only.NJM2845DL1-23-TE1
IC REG LINEAR 2.3V 800MA TO252-3
DatasheetTO-252-3, DPAK (2 Leads + Tab), SC-63
53,591 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Fixed 1 Output 800mA TO-252-3
NJM2845DL1-23-TE1
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | Nisshinbo Micro Devices Inc. |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS non-compliant |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 14V |
| Voltage - Output (Min/Fixed) | 2.3V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 0.28V @ 500mA |
| Current - Output | 800mA |
| Current - Quiescent (Iq) | 600 µA |
| PSRR | 75dB (1kHz) |
| Control Features | - |
| Protection Features | Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 85°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Supplier Device Package | TO-252-3 |
| Base Product Number | NJM2845 |
| Current - Supply (Max) | - |
| Product Attribute | |
 |
|
 |
| Part Number | NJM2845DL1-23-TE1# | NJM2845DL1-03-TE1 | NJM2845DL1-03-TE1# | NJM2845DL1-05-TE1 |
| Manufacturer | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. |
| RoHS Status | RoHS Compliant | RoHS non-compliant | RoHS Compliant | |
| Description | IC REG LINEAR 2.3V 800MA TO252-3 | IC REG LINEAR 3V 800MA TO252-3 | IC REG LINEAR 3V 800MA TO252-3 | IC REG LINEAR 5V 800MA TO252-3 |
| Series | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) |
