PCN10-20P-2.54DSA
Manufacturer
Hirose Electric Co LtdDescription
CONN DIN HDR 20POS PCB GOLD
Datasheet
DatasheetPackage
-
In Stock
64,287 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
PCN10-20P-2.54DSA
PCN10-20P-2.54DSA
lmages are for reference only.Payment Methods
Delivery Services
20 Position Din Connector Header, Male Pins Gold Through Hole
Quick Inquiry
PCN10-20P-2.54DSA
Specifications
| Category | Connectors, Interconnects - Backplane Connectors - DIN 41612 |
| Manufacturer | Hirose Electric Co Ltd |
| Series | PCN10 |
| Packaging | Tray |
| RoHS Status | RoHS non-compliant |
| Connector Type | Header, Male Pins |
| Number of Positions | 20 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Style | B |
| Level, Class | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 8.00µin (0.203µm) |
| Operating Temperature | -55°C ~ 85°C |
| Current Rating (Amps) | 2A |
| Material Flammability Rating | UL94 V-0 |
| Material - Insulation | Polybutylene Terephthalate (PBT) |
| Base Product Number | - |
