PSMN9R0-25MLC,115
lmages are for reference only.PSMN9R0-25MLC,115
MOSFET N-CH 25V 55A LFPAK33
DatasheetSOT-1210, 8-LFPAK33 (5-Lead)
33,763 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 25 V 55A (Tc) 45W (Tc) Surface Mount LFPAK33
PSMN9R0-25MLC,115
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Nexperia USA Inc. |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 25 V |
| Current - Continuous Drain (Id) @ 25°C | 55A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 8.65mOhm @ 15A, 10V |
| Vgs(th) (Max) @ Id | 1.95V @ 1mA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 705 pF @ 12.5 V |
| FET Feature | - |
| Power Dissipation (Max) | 45W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | LFPAK33 |
| Package / Case | SOT-1210, 8-LFPAK33 (5-Lead) |
| Base Product Number | PSMN9R0 |
| Gate Charge (Qg) (Max) @ Vgs | 11.7 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
|
| Part Number | PSMN9R0-25YLC,115 | PSMN9R0-30LL,115 | PSMN9R0-30YL,115 | PSMB032N08NS1_R2_00601 |
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | Panjit International Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET N-CH 25V 46A LFPAK56 | MOSFET N-CH 30V 21A 8DFN | MOSFET N-CH 30V 61A LFPAK56 | 80V/ 3.4MOHM / MV MOSFET |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
