PSX1XLDB0450X
lmages are for reference only.PSX1XLDB0450X
FUSE SEMI 1500VDC 1XL SIZE 450A
DatasheetRectangular, Blade
34,853 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
450A 1.5 kVDC Fuse Square Bolt Mount
PSX1XLDB0450X
| Category | Circuit Protection - Electrical-Specialty Fuses - |
| Manufacturer | Littelfuse Inc. |
| Series | POWR-SPEED® PSX |
| Packaging | Box |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Bolt Mount |
| Fuse Type | Square |
| Current Rating (Amps) | 450A |
| Voltage Rating - AC | - |
| Response Time | Fast Blow |
| Applications | Semiconductors |
| Features | Indicating |
| Class | - |
| Approval Agency | CE, cURus, UL |
| Operating Temperature | -55°C ~ 125°C |
| Breaking Capacity @ Rated Voltage | 200kA |
| Package / Case | Rectangular, Blade |
| Size / Dimension | 4.988" L x 2.028" W x 2.264" H (126.70mm x 51.50mm x 57.50mm) |
| Base Product Number | - |
| Voltage Rating - DC | 1.5 kVDC |
| Grade | - |
| Qualification | - |
| Melting I²t | 149336.0 |
| DC Cold Resistance | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | PSX1XLDB0400X | PSX1XLDB0080X | PSX1XLDB0100X | PSX1XLDB0125X |
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FUSE SEMI 1500VDC 1XL SIZE 400A | FUSE SEMI 1500VDC 1XL SIZE 80A | FUSE SEMI 1500VDC 1XL SIZE 100A | FUSE SEMI 1500VDC 1XL SIZE 125A |
| Series | POWR-SPEED® PSX | POWR-SPEED® PSX | POWR-SPEED® PSX | POWR-SPEED® PSX |
| Packaging | Box | Box | Box | Box |
